Licznik Wody Diehl Aries IS IZAR

alecsandes · 19 Październik 2023 22:10

Hello People,

I am desperate to find out where is the issue:

I have the water meter:

I have tried 2 ways of reading the telegrams:

zibous/ha-watermeter/blob/master/RTL232.md

# Raspbian Buster + DVB-T receiver


### ![RB3B_DVBT](docs/RB3B_DVBT.png)
<br>

**Andoer Tragbarer Mini Digitaler TV Stock USB 2.0 DVB-T+DAB+FM+RTL2832U+FC0012 Chip Unterstützung SDR**

![SDR_STICK](docs/SDR_STICK.png)


Digitaler TV Stock USB 2.0 DVB-T + DAB + FM + RTL2832U + FC0012 see: [Amazon](https://amzn.eu/d/8NNDo6A).

Details and Installation see:  [wmbusmeters-with-rtl-sdr.md](docs/wmbusmeters-with-rtl-sdr.md)


### Requirements

- Water meter with IZAR module (Diehl IZAR RC 868 I R4 PL),
  IZAR Radio Compact Hall is designed for mobile reading and fixed network remote reading of Diehl Metering meters.

This file has been truncated. show original

running $ rtl_sdr -f 868.625M -s 1600000 - 2>/dev/null | rtl_wmbus -s

I get a lot of telegrams like:
T1;1;1;2023-10-19 21:58:02.000;102;147;215091CD;0x1944304ccd9150211404a22313001349151047a9a90de3748cbd
T1;1;1;2023-10-19 21:58:02.000;144;126;215091CD;0x1944304ccd9150211404a22313001349151047a9a90de3748cbd

If I take one telegram
https://wmbusmeters.org/analyze/1944304ccd9150211404a22313001349151047a9a90de3748cbd

There is no data decoded in it.
Here is the detailed issue

github.com/ZeWaren/izar-prios-smart-meter-collector

Help needed

opened 07:43PM - 21 Sep 23 UTC

alecsandes

Hi @ZeWaren I have tagged you in the wmbusmeters github as well and trying h…ere, maybe you will see this and guide me. I used this tutorial and setup: https://github.com/zibous/ha-watermeter/blob/master/docs/wmbusmeters-with-rtl-sdr.md (raspberry 4 instead of pi zero) I have this meter: ARIES IS Water meter https://www.diehl.com/metering/en/products-solutions/products-services/water-metering/aries-is-at/ IZAR integrated 868 MHz and 434 MHz radio, PRIOS protocol When running: `rtl_sdr -f 868.625M -s 1600000 - 2>/dev/null | rtl_wmbus -s ` I get a lot of: `T1;0;0;2023-09-13 22:21:22.000;68;54;FFFFFFFF;0x1944ff26ffffffff9404ffa0608860ffffffff7cffffff7bffff T1;0;0;2023-09-13 22:21:22.000;38;64;2150912A;0x1944304c2a915021ff04a2731300132ce3a7ff7ca35c79262eff T1;0;0;2023-09-13 22:21:22.000;100;106;FFFF94FF;0x19ffffffff94ffff1404a22313ff13bbfffffffffffffff035ff T1;1;1;2023-09-13 22:21:23.000;98;113;214FF95F;0x1944304c5ff94f211404a2231300137a2b5171294f5213d75289 T1;0;0;2023-09-13 22:21:24.000;25;40;FFFFFFFF;0x19ffff4cffffffff14ffff331300ffff547eb5ffffa571a4ffb3 T1;0;0;2023-09-13 22:21:26.000;97;141;2150A874;0x19ff304c74a850211404a253140013f3f85ec84eff1a8a291994 T1;1;1;2023-09-13 22:21:27.000;107;140;215091CD;0x1944304ccd9150211404a253130013494eddbbf85437ee75c3b3 T1;0;0;2023-09-13 22:21:27.000;145;118;215091CD;0x1944304ccd9150211404a253130013494eddbbf85437ee77ffff ` When Running: `wmbusmeters --format=json auto:t1 MyWater izar '*' NOKEY` I get a lot of: `Started auto rtlwmbus[00000001] listening on t1 (izar) Decoding PRIOS data failed. Ignoring telegram. {"media":"water","meter":"izar","name":"MyWater","id":"214ff7d6","prefix":"","serial_number":"000000","total_m3":0,"last_month_total_m3":0,"last_month_measure_date":"0-00-00","remaining_battery_life_y":0,"current_alarms":"no_alarm","previous_alarms":"no_alarm","transmit_period_s":0,"manufacture_year":"0","timestamp":"2023-09-13T22:23:49Z","device":"rtlwmbus[00000001]","rssi_dbm":97} ` When running: `sudo wmbusmeters --debug --t1 rtlwmbus` I get a lot of: (`main) regular reset of rtlwmbus will happen every 82800 seconds (wmbus) no alarm (expected activity) for rtlwmbus (serial) registered regular callback HOT_PLUG_DETECTOR(0) every 2 seconds No meters configured. Printing id:s of all telegrams heard! (serial) waiting for stop (serial) received ascii "T1;1;1;2023-09-13 22:24:58.000;105;123;215091CD;0x1944304ccd9150211404a233130013493c3e0e0290df3aaf95bc<0A>T1;1;1;2023-09-13 22:24:58.000;141;115;215091CD;0x1944304ccd9 ![204155722-9746eb5f-ce6b-455d-bda6-2f8f57cf0a21]x 150211404a233130013493c3e0e0290df3aaf95bc<0A>" (rtlwmbus) checkRTLWMBusFrame "T1;1;1;2023-09-13 22:24:58.000;105;123;215091CD;0x1944304ccd9150211404a233130013493c3e0e0290df3aaf95bc<0A>T1;1;1;2023-09-13 22:24:58.000;141;115;215091CD;0x1944304ccd9150211404a233130013493c3e0e0290df3aaf95bc<0A>" (rtlwmbus) received full frame (meter) no meter handled checking 0 templates. (diehl) preprocess necessary SAP_PRIOS (diehl) Pre-processing: setting device type to water meter for SAP PRIOS (wmbus) parseDLL @0 26 (wmbus) parseELL @10 16 (wmbus) parseNWL @10 16 (wmbus) parseAFL @10 16 (wmbus) parseTPL @10 16 (diehl) preprocess necessary SAP_PRIOS (diehl) Pre-processing: setting device type to water meter for SAP PRIOS (wmbus) parseDLL @0 26 (telegram) DLL L=19 C=44 (from meter SND_NR) M=4c30 (SAP) A=215091cd VER=00 TYPE=07 (Water meter) (driver izar) DEV=rtlwmbus[00000001] RSSI=105 (wmbus) parseELL @10 16 (wmbus) parseNWL @10 16 (wmbus) parseAFL @10 16 (wmbus) parseTPL @10 16 (telegram) TPL CI=a2 Received telegram from: 215091cd manufacturer: (SAP) Sappel (0x4c30) type: Water meter (0x07) ver: 0x00 device: rtlwmbus[00000001] rssi: 105 dBm driver: izar (wmbus) 000 : 19 length (25 bytes) (wmbus) 001 : 44 dll-c (from meter SND_NR) (wmbus) 002 : 304c dll-mfct (SAP) (wmbus) 004 : cd915021 dll-id (215091cd) (wmbus) 008 : 00 dll-version (wmbus) 009 : 07 dll-type (Water meter) (wmbus) 010 : a2 tpl-ci-field (Mfct specific) (wmbus) 011 C?: 33130013493C3E0E0290DF3AAF95BC mfct specific (wmbus) telegram from 215091cd ignored by all configured meters! (rtlwmbus) checkRTLWMBusFrame "T1;1;1;2023-09-13 22:24:58.000;141;115;215091CD;0x1944304ccd9150211404a233130013493c3e0e0290df3aaf95bc<0A>" (rtlwmbus) received full frame (wmbus) skipping already handled telegram leng=26. ` I was comparing the data what I have with what you posted on your blog: `Decoding a Sappel frame Let’s look at a full frame received by the antenna of my circuit: 01010101010101010101010101010101010101 0000111101b + 1944304CC697D720D401E2E6A213120013184587BD6EB979401E8B407096h ` I have as a frame (filtered the ones with 19 44 like this ``` rtl_sdr -f 868.625M -s 1600000 - 2>/dev/null | rtl_wmbus -s T1;1;1;2023-09-21 19:32:21.000;101;127;2150A9FA;0x1944304cfaa950211404a2231400134a2c75e61a25bb0d891f7d ``` If I would compare what is obvious to my eyes: Your example: `1944304CC697D720D401E2E6A213120013184587BD6EB979401E8B4` Mine: `1944304cfaa950211404a2231400134a2c75e61a25bb0d891f7d` I am several chars less Can you help me understand what is wrong?

and CC1101 with ESP8266 presented here.
However, the CC1101 board I sourced is this

it has 433 written on it … but I get the same readings:

[00:24:37][D][wmbus:179]: Meter ID [0x2150A86F] RSSI: -86 dBm LQI: 129 Mode: T1 not found in configuration T: 1944304C6FA850211404A2231300131650E0B2A913F17D47099E (26)
[00:24:38][D][wmbus:179]: Meter ID [0x2150A9F8] RSSI: -86 dBm LQI: 128 Mode: T1 not found in configuration T: 1944304CF8A950211404A203330013017241955F03ABC73A7840 (26)
[00:24:41][D][wmbus:179]: Meter ID [0x216049FD] RSSI: -96 dBm LQI: 132 Mode: T1 not found in configuration T: 1944304CFD4960211404A2731500130D3E27E125F1D92091DC0C (26)
[00:24:41][D][wmbus:179]: Meter ID [0x214FD95F] RSSI: -94 dBm LQI: 129 Mode: T1 not found in configuration T: 1944304C5FD94F211404A25313001378544D9642A77F66128E67 (26)
[00:24:42][D][wmbus:179]: Meter ID [0x215091DC] RSSI: -81 dBm LQI: 128 Mode: T1 not found in configuration T: 1944304CDC9150211404A2231300135EBE4BB1354343F689C8A6 (26)

Here is the link to the wmbusmeters page:
https://wmbusmeters.org/analyze/1944304CDC9150211404A2231300135EBE4BB1354343F689C8A6

I don’t know really how to take it further, there are several points which i have doubts:

Meter is R3 not R4 as most of the people here:
Frequency MHz 868.95 (R3 mode) and 434.47 (R3 mode)**
Measuring with a DVB-T with command
rtl_sdr -f 868.625M -s 1600000 - 2>/dev/null | rtl_wmbus -s
i get a lot of readings

Reading with rtl_sdr -f 868.950M -s 1600000 - 2>/dev/null | rtl_wmbus -s
I get none …

Reading with rtl_sdr -f 434.47M -s 1600000 - 2>/dev/null | rtl_wmbus -s
I get none.

If the CC1101 board is 433 MHz why can I see the telegrams I receive with rtl_sdr -f 868.625M -s 1600000 - 2>/dev/null | rtl_wmbus -s

I am beyond my knowldgeand I haven’t seen somenone facing the same issue
